Call UsVermeer TE330 Tedder / NOT AVAILABLE
Tedders TE330 Tedder
Overview:
Designed to maneuver like a model half its width, the TE330 gives you an impressive 33.5'/10.2 m of tedding action. Tight turning circle and constant-velocity U-joints improve handling. Unique trailed framework and hydraulic lift and fold provide convenient transporting. Double-framed construction stabilizes tedder arm... + Read More
Features
EASY TO TRANSPORT
Easy and simple to transport, with the transport tires and cart.
ADJUSTABLE ROTOR ANGLES
Adjust rotor angles without tools to match crop and field conditions, using the wheel settings under the rotors.
ADJUSTABLE TINES
Work along fences and field edges by setting the tines to the inner position to feed the crop directly behind the machine.
ANTI-WRAP PLATES
Keep working, not wrapping thanks to the Vermeer anti-wrap plates and curved wheel supports that keep the crop from wrapping around the wheels.
LIMITED WARRANTY
Protect your investment. Vermeer “hook” tines are the only ones in the industry with a 3-year limited warranty.
Specifications
| STANDARD FEATURES | |
| SMV Sign | Yes |
| Tail Lights | Yes |
| TRACTOR REQUIREMENTS | |
| PTO Horsepower Requirements | 60 hp |
| Hydraulic requirements | 2 double-acting |
| Hydraulic Pressure | 2100 psi |
| Hitch | Drawbar |
| Drive - PTO | 540 rpm |
| DIMENSIONS AND WEIGHTS - APPROXIMATE | |
| Tedding width | 33.5 ft |
| Transport Height | 9.5 ft |
| Transport Width | 9.8 ft |
| Transport Length | 18.9 ft |
| Weight | 5260 lbs |
| Tire size | 16 x 6.5-8 |
| Tire Size - Transport | 10.0 x 75-15.3 |
| Basket Angle Range | 10-17° |
| Basket Angle Adjustment Style | Adjustable by changing wheel frame/main frame mount |
| Number of Baskets | 8 |
| Tine Arms per Basket | 7 |
| Type of Tine | Hook Tine |
| Torque Protection - Driveline | Radial pin clutch |
| Operating Speed (Maximum) | 9.3 mph |
| OPTIONS | |
| Safety Chain | Yes |
| Warranty | 3-year hook tine warranty |
